Predator Dual Bearing Billet Sidecover, Non-Hemi

Predator Dual Bearing Billet Sidecover, Non-Hemi
Predator Dual Bearing Billet Sidecover, Non-Hemi
$146.95/EACH
ItemARC-6068

Description

The ARC 6068 billet sidecover is designed specifically for Gen 1 and Gen 3 NON-HEMI Harbor Freight Predator 212cc engines and delivers a significant upgrade in strength, stability, and durability over the stock cast cover.

Machined from high-strength billet aluminum, it features a dual ball bearing design that provides additional crankshaft support, reducing flex and improving stability at high RPM. A bronze-bushed camshaft support with ARC’s advanced oiling system helps reduce wear and increase long-term reliability in racing applications.

An integrated O-ring seal ensures excellent crankcase sealing, while precision dowel pin receptacles improve alignment and structural strength. Additional features include dual oil fill ports with billet plugs, 1/8" NPT vent ports, and threaded removal points for easier servicing.

Built for serious performance applications, the ARC 6068 is ideal for racing engines where strength, consistency, and durability are critical. This part is intended to replace the ARC-6058.

Key Features

  • Side-by-side dual ball bearing crankshaft support
  • Bronze bushed camshaft support with advanced oiling system
  • Precision-machined billet aluminum construction
  • Integral O-ring seal for leak-free performance
  • Four dowel pin receptacles for increased shear strength
  • Two top vent ports with 1/8" NPT plugs
  • Dual oil fill ports with billet aluminum hand-tighten plugs
  • Threaded push-out holes for easier sidecover removal
  • M8x1.25mm chain guard mounting hole

Performance Characteristics

  • Reduces crankshaft flex at high RPM
  • Improves crankshaft stability and bottom-end strength
  • Enhances crankcase rigidity
  • Improves oil control and sealing performance
  • Increases durability in high-stress racing applications

Included Components

  • Bearings
  • Bronze camshaft bushing
  • Seal, gasket, and O-ring
  • Oil fill plugs and vent plugs
  • Installation hardware
  • Two solid dowel pins (top and bottom receptacles)
  • Written installation instructions

Torque Specification

185-200 in/lbs


Fitment

  • Harbor Freight Predator 212cc NON-HEMI (Gen 1 & Gen 3 only)

Fitment Limitations

  • Will NOT fit Honda GX200 / 196cc Clone engines
  • Will NOT fit Ducar 196 / 212 / 224 engines
  • Will NOT fit Tillotson 196 / 212 / 225 / 235 engines
  • Will NOT fit Predator 212 Hemi engines
  • Will NOT fit Predator Ghost engines
  • Will NOT fit Predator 224cc engines
